Eikon WM700DMA Duplo Mão

165,00

Sistema sem fio de Mão duplo Eikon

Indisponível

Descrição

DUAL CHANNEL PLL UHF WIRELESS HANDHELD MICROPHONE SYSTEM

EIKON’s WM101 V2 series is a complete range of single or dual channel wireless products with handheld transmitters or bodypack transmitters with headset microphone.

This line of products offers a particularly interesting value for money, thanks to the quality capsule of the transmitters and the Digital Encrypting system with 3 available channels.

Single-channel systems include a rugged ABS housing while dual-channel systems include a solid metal chassis.

  • The WM700 wireless microphone system is a PLL controlled UHF variable frequency device, which provides reliable and high quality signal transmission, thanks also to the Digital Tone Pilot.
  • The WM700 wireless microphone system offers 5 different combinations with single channel receiver, dual channel receiver, handheld transmitter and bodypack transmitter with headset microphone.
  • The system is available in 2 different bands with groups of 16 or 32 pre-set frequencies to be used also simultaneously.



  • Each configuration includes an ABS case.
    • PLL –16 CH Selectable frequency Dual Channel wireless microphone system
    • 32 Khz Digital Tone Pilot
    • New durable Painting Finishing
    • Universal USB Power Adapter
    • 823 – 832 Mhz or 512 – 562 Mhz (WM700DMA) frequency range
    • 30 meter/ 100 feet range
    • 50 Hz -15 KHz frequency response
    • 105 dB signal/ noise ratio
    • 2 x handheld transmitter with cardioid dynamic capsule
    • Up to 4 frequency usable in the same location for each Frequency band.
    • ABS carrying and storage case



RECEIVER

  • Frequency Band UHF: 823-832 MHz or 512 – 562 Mhz (WM700DMA)
  • RF Sensibility -105 dBm
  • RF Image/Spurious Rej. >70 dB
  • RF Interference Reject. >70 dB
  • RF Frequency Stability ±0.002%
  • THD Distortion <1%
  • S/N Ratio >105 dB
  • Frequency Response 50 Hz – 15 KHz (±3 dB)
  • Power Supply 5 V DC 500 mA
  • Dimensions (mm) 175 x 135 x 45



HANDHELD TRANSMITTER

  • RF Frequency Band UHF: 823-832 MHz or 512 – 562 Mhz (WM700DMA)
  • RF Power <10 dBm
  • Modulation method FM (F3E)
  • RF Max deviation ±40 KHz
  • RF Frequency Stability ±0.002%
  • Spurious Emission under limits EN 300422
  • Frequency Response 50 Hz – 15 KHz (±3 dB)
  • Power Supply 2×1.5V AA alkaline bat
  • Dimensions (mm) 235 x 50 x 50
